  • DSP2000
  • DSP2000
  • Reaching an output power of 2x1050W @4Ohm, employs SMPS technology for power-supply stage and D-class for output stage, weighing 96,8kg only.
    Equipped with a 32/64 bit floating-point and 96kHz sampling rate DSP.
    These features make DSP2000 the right choice for professional loudspeakers and for Sub/MF/HF sections of multi-amplified systems.
    TECHNICAL DATA DSP2000
    8 Ohm stereo power (EIA/THD1%) 650Wx2
    4 Ohm stereo power (Pulse) THD1%) 1050Wx2
    8 Ohm bridge power (Pulse THD1%) 2100W
    Frequency response 20Hz-20Khz@ 8 Ohm -0.5 dB
    THD+N <0.1%
    Damping factor >60
    S/N rate >96dB
    Input sensitivity/gain 1Vrms/32dB/38dB
    Input impedance (balance/unbalance) Balance 20K / Unbalance 10K
    Output circuit class D class
    Protection Soft-start, short circuit, overload, DC, overheat, clip/limit, progressive volume
    Cooling air-flow Airflow from front panel to rear panel.
    DSP specification
    Crossover filtering Bessel. Butt. Link.-Riley (12,18,24.48dB/Oct.)
    8- band Eq type Full paramtric, high shelf-low shelf (6-12dB/Oct.)
    EQ gain Adjustable from -20dB to +20dB
    Crossover/Eq freq. band 20Hz to 20kHz, 1/36Oct.step pitch (19980 position)
    Full parametric eq filter Q Adjustable from 0.404 to 28.852
    Maximum delay 1S
    Limiter threshhold Adjustable from +20dBu to -20dBu,0,1dBu steps
    Limiter release time Adjustable to 2/4/6/8/16/32 x the attack time
    Attack time Adjustable from 0.3 to 100 ms
    Power voltage / frequency ~230V 10%/50Hz
    Dimensions (WxHxD) 483x89x382mm
    Net weight 6.8Kg
    Gross weight 8Kg
    For the product no accessories are related, for more information please consult the catalogue or the relevant user manual

    Firmware

    Accomplish more with our product updates
    Make sure you always get your product updated to the most recent software/hardware versions to obtain the best result out of your fixture and your show.
    Collecting feedbacks from users, we constantly add new capabilities, and improve customer experience and  technical endurance.
    Get in touch with our team for any questions or assistance.

    Drawings

    Catalogues

    #0Not available

    Fixture Libraries / DMX Charts

    Photometrics

    Software Upgrades

    DAD DSP Amp ControlDownload

    User Manuals


    Italian/English manual
    Download
