TOURING112HP
Share me

Immagine Principale
  • TOURING112HP
  • TOURING112HP
  • TOURING112HP
  • TOURING112HP
  • High-efficiency passive loudspeaker, horn-loaded configuration, 2-way 500W AES, 138dB SPL

    Features:
    Low frequency: 12'' neodymium woofer/3''v.c.
    High frequency: 1.4'' neodymium driver/3''v.c.
    Frequency response: 80-18000 Hz (±3dB)
    Excellent clarity in the reproduction of voice and music for live and recorded performances
    For sound installations in indoor/outdoor environments requiring dynamics and high sound pressure over long distances
    Birch plywood enclosure

    LOUDSPEAKER
    • System type:
      coaxial horn loaded
    COMPONENTS
    • Low frequency:
      12
      ''
      neodymium woofer / 3'' v.c.
    • High frequency:
      1.4
      ''
      neodymium driver / 3'' v.c.
    FEATURES
    • AES/program power:
      510/1020
      W
    • SPL max:
      138
      dB
      @1m (free field)
    ACOUSTICAL SPECIFICATIONS
    • Sensitivity:
      105
      dB
    • Impedance:
      8 Ohm
    • SPL cont/peak:
      132/138
      dB
      @1m (free field)
    • Frequency response:
      80-18000
      Hz
      (±3dB)
    • Coverage angle HxV:
      75x40
      °
    • Cross over frequency:
      1000
      Hz
    • Protection:
      H.F. signal compression
    • Suggest HPF range:
      100/150
      Hz
    • Recommended amplifier up to:
      1000
      W
      /8Ohm
    INPUT/OUTPUT CONNECTORS
    • Input signal:
      Neutrik NL4 IN/OUT
    CABINET CONSTRUCTION
    • Cabinet material:
      18
      mm
      birchplywood
    • Sospension system:
      eyebolt, fly track, 35 mm pole mount
    • Angle:
      26
      °
      trapezoidal taper
    • Handles:
      6 on side
    PHYSICAL
    • Dimensions (WxHxD):
      560x590x600
      mm
    • Weight:
      35
      kg
    Product Code
    Accessory Code
    Description
    TOURING112HP (optional)
    TOURING112H (optional)
    Plywood skate for TOURING12H/TOURING12HP
    TOURING112HP (optional)
    ROAD10 (optional)
    FUSION12A (optional)
    FUSION10A (optional)
    TOURING15MP (optional)
    TOURING12MP (optional)
    TOURING215P (optional)
    FUSION15A (optional)
    FUSION12MA (optional)
    FUSION15MA (optional)
    FUSION10P (optional)
    FUSION12P (optional)
    FUSION15P (optional)
    FUSION12MP (optional)
    TOURING15P (optional)
    TOURING12P (optional)
    TOURING208A (optional)
    TOURING10A (optional)
    TOURING12A (optional)
    TOURING15A (optional)
    TOURING215A (optional)
    TOURING12MA (optional)
    TOURING15MA (optional)
    TOURING208P (optional)
    TOURING10P (optional)
    FUSION15MP (optional)
    TOURING112H (optional)
    Steel rope (6mm diam.) for suspension, ACCA5452 incl., 30cm L
    TOURING112HP (optional)
    TOURING215P (optional)
    TOURING12MP (optional)
    TOURING15MP (optional)
    FUSION10A (optional)
    FUSION12A (optional)
    FUSION15A (optional)
    FUSION12MA (optional)
    FUSION15MA (optional)
    FUSION10P (optional)
    FUSION12P (optional)
    FUSION15P (optional)
    FUSION12MP (optional)
    TOURING15P (optional)
    TOURING12P (optional)
    TOURING208A (optional)
    TOURING10A (optional)
    TOURING12A (optional)
    TOURING15A (optional)
    TOURING215A (optional)
    TOURING12MA (optional)
    TOURING15MA (optional)
    TOURING208P (optional)
    TOURING10P (optional)
    FUSION15MP (optional)
    TOURING112H (optional)
    Steel rope (6mm diam.) for suspension, ACCA5452 incl., 30cm L
    TOURING112HP (optional)
    TOURING215P (optional)
    TOURING12MP (optional)
    TOURING15MP (optional)
    FUSION10A (optional)
    FUSION12A (optional)
    FUSION15A (optional)
    FUSION12MA (optional)
    FUSION15MA (optional)
    FUSION10P (optional)
    FUSION12P (optional)
    FUSION15P (optional)
    FUSION12MP (optional)
    TOURING15P (optional)
    TOURING12P (optional)
    TOURING208A (optional)
    TOURING10A (optional)
    TOURING12A (optional)
    TOURING15A (optional)
    TOURING215A (optional)
    TOURING12MA (optional)
    TOURING15MA (optional)
    TOURING208P (optional)
    TOURING10P (optional)
    FUSION15MP (optional)
    TOURING112H (optional)
    Steel rope (6mm diam.) for suspension, ACCA5452 incl., 50cm L
    TOURING112HP (optional)
    TOURING112H (optional)
    Tensioning belt ratchet, 35mm, L.8m, 2000 kg capacity
    TOURING112HP (optional)
    TOURING112H (optional)
    Fabric protection for DAD TOURING12H/TOURING12HP, TOURING112H/TOURING12HP
