PanoramaIP Spot
ORDER CODE: PANORAMAIPSPOT
Share me

IP65

Immagine Principale
  • PANORAMAIPSPOT
  • PANORAMAIPSPOT
  • PANORAMAIPSPOT
  • PANORAMAIPSPOT
  • PanoramaIP Spot is a powerful and flexible IP65 rated moving LED spot designed to deliver a stunning brightness level, all packaged in a compact housing. Equipped with a 1:10 zoom and a complete feature set, PanoramaIP Spot really stands out in any environment, from festivals and arenas to large outdoor events.

    Features:
    IP65 rated for outdoor events and temporary installations.
    420 W high power LED with 7.000 K CT and 5° - 50° linear zoom.
    Extensive range of effects including linear CMY and CTO mixing, colour wheel, rotating gobo wheel, static gobo wheel, circular prisms, linear frost and focus.

    LIGHT SOURCE
    • Source:
      420
      W
      high-power white LED
    • CCT:
      7.000
      K
    • Lux:
      (5°) 21'362
      lx
      @5 m full
    • Lux:
      (50°) 1'173
      lx
      @5 m full
    • Source life expectancy:
      > 20.000 h
    OPTICS
    • Zoom:
      5° - 50
      °
      motorised linear zoom
    • Lens diameter:
      120
      mm
    • Lens type:
      HD anti-reflection lenses with achromatic coating
    • Focus:
      motorised with auto-focus
    COLOUR SYSTEM
    • Colour mixing:
      linear CMY
    • CCT:
      linear CTO correction 2.700 K ~ 6.000 K
    • Colour wheel:
      8
      colour filters
    DYNAMIC EFFECTS
    • Rotating gobos:
      7
      rotating gobos + open, interchangeable, indexing
    • Gobo size:
      outer: 26 mm - image: 19 mm - max thickness: 2 mm
    • Fixed gobos:
      6
      fixed gobos + open, interchangeable
    • Gobo size:
      outer: 26 mm - image: 19 mm - max thickness: 0,5 mm
    • Circular prism:
      3
      f
      with bi-directional rotation, indexing
    • Frost:
      linear 0 - 100% frost filter
    • Iris:
      5 - 100
      %
      motorised iris
    BODY
    • Pan angle:
      540 - 630
      °
    • Tilt angle:
      233
      °
    • Pan/Tilt resolution:
      bit
      8 / 16-bit
    • Feedback:
      automatic repositioning after accidental movement
    • Body:
      aluminium structure with high-resistance polycarbonate cover
    • Body colour:
      black
    CONTROL
    • Protocols:
      DMX512, RDM, Art-Net, W-DMX
    • DMX channels:
      19 / 21 / 28 / 29 / 36
      channel
    • Wireless Control:
      included, wireless solution receiver
    • RDM:
      RDM for remote monitoring and settings
    • Display:
      LCD high resolution colour display
    • Firmware upgrade:
      yes, via USB - DMX interface (UPBOX2) not included
    • Hibernation:
      power safe mode when lost DMX
    ELECTRONICS
    • Dimmer:
      linear 0 ~ 100% electronic dimmer
    • Strobe / shutter:
      1 - 28
      Hz, electronic
    • Display battery:
      self-charging battery backup
    • Operating temperature:
      -20° ~ +40°
    ELECTRICAL
    • Mains power supply:
      100-240V - 50/60Hz
    • Max power consumption:
      492
      W
    • Max power consumption (at 120V):
      501
      W
    PHYSICAL
    • IP rating:
      65
      for temporary outdoor application, not for fixed installation
    • Cooling:
      combination of heat pipe cooling system and low noise fan
    • Suspension and fixing:
      any position with quick-lock omega brackets
    • Pan / tilt lock:
      for transportation and maintenance
    • Signal connection:
      Amphenol XLR 5p IN/OUT connectors
    • Data connection:
      Art-Net
      RJ45 IN/OUT
    • Power connection:
      Seetronic powerCON waterproof IN/OUT connectors
    • Dimensions (WxHxD):
      441x740x315
      mm
    • Weight:
      38
      kg
    CERTIFICATIONS / APPROVALS
    • Certifications / Approvals:
      CE, UKCA, RCM
    BOX CONTENT
    • 1 x PANORAMAIPSPOT
    • 1 x 1,5 meters power cable (SCHUKO plug - SEETRONIC IP65 power connector)
    • 2 x OSIP
    • 1 x Antenna
    • User Manual
