    Code CT CRI Lumen Avail.
    MINIECLIPSETU 3100K 93Ra 612lm
    MINIECLIPSEDY 6000K 91Ra 700lm

    MINIECLIPSE is a new concept of mini LED ellipsoidal. Demonstrating a stylish design, ease of use, precise optics, sharp image projection and bright even projection - all in a compact housing that is just a quarter of the size of the traditional ellipsoidal fixtures. MINIECLIPSE is designed for applications in commercial spaces, museums, restaurants, churches, educational theatres and any other installation where size is an important factor. Available in tungsten and daylight versions, MINIECLIPSE performs even field projection with high CRI at any level of brightness and linear dimmer over the entire curve.



    Features:
    Bright and compact LED ellipsoidal with sharp optics and shutters
    Available with warm and cold white high CRI LED sources
    19° - 26° - 36° - 50° lens options

    LIGHT SOURCE
    • Source:
      28
      W
      CREE LED
    • CT:
      TU 3.100 K - DY 6.000
      K
    • CRI:
      TU 93 - DY 91
    • Luminous flux:
      TU 612 lm - DY 700
      lm
    • Lux:
      TU 880 lx - DY 1'037
      lx
      @3 m - 19°
    • Source life expectancy:
      > 50.000 h
    OPTICS
    • Beam angle:
      optional 19° / 26° / 36° / 50
      °
    • Lens type:
      high-quality glass lens optics
    DYNAMIC EFFECTS
    • Fixed gobos:
      gobo holder Included in optics
    • Gobo size:
      E, outer: 37,3 mm - image: 24 mm - thickness: 1,1 mm
    • Static colour mode:
    • Manual colour mode:
      manual adjustment of dimmer and strobe
    BODY
    • Body:
      sturdy die-cast aluminium body conceived for long-time durability
    • Body colour:
      black
    ELECTRONICS
    • Dimmer:
      linear 0 ~ 100%, manual knob dimmer
    • Operating temperature:
      -10° ~ +45°
    • Flicker:
      flicker free operation
    ELECTRICAL
    • Power supply:
      100-240 V – 50/60 Hz
    • Power consumption (at 230 V):
      29
      W
    PHYSICAL
    • Cooling:
      natural cooling of the peculiar chassis and to absence of fans
    • Sospension and fixing:
      hanging bracket suitable for safe hanging and positioning
    • Power connection:
      moulded IP power IN connector
    • IP rating:
      20
    • Dimensions (WxHxD):
      112x176x226
      mm
    • Weight:
      1
      kg
    Product Code
    Accessory Code
    Description
    MINIECLIPSE (optional)
    MINIECLIPSEWD (optional)
    Optics for MINIECLIPSE profiler, gobo holder included, 19° beam
    MINIECLIPSE (optional)
    MINIECLIPSEWD (optional)
    Optics for MINIECLIPSE profiler, gobo holder included, 26° beam
    MINIECLIPSE (optional)
    MINIECLIPSEWD (optional)
    Optics for MINIECLIPSE profiler, gobo holder included, 36° beam
    MINIECLIPSE (optional)
    MINIECLIPSEWD (optional)
    Optics for MINIECLIPSE profiler, gobo holder included, 50° beam
    MINIECLIPSE (optional)
    MINIECLIPSETR (include)
    MINIECLIPSETRWD (include)
    GALLERYECLIPSE (optional)
    GALLERYECLIPSEFC (optional)
    MINIECLIPSEWD (optional)
    Track adaptor
