ArcPod 48Q
ORDER CODE: ARCPOD48Q
Share me

IP66

Immagine Principale
  • ARCPOD48Q
  • ARCPOD48Q
  • ARCPOD48Q
  • ARCPOD48Q

    • ArcPod 48Q is a compact high-power exterior wash light featuring an outstanding brightness of 23'000 lumens. It is equipped with 48x10W RGBW / FC LEDs, delivering a limitless reproduction of colours and whites. ArcPod 48Q is designed slim and fanless, and it's completed by a wide selection of available optics, making the ArcPod 48Q an incredibly flexible and versatile device for any outdoor install.

    Features:
    48x10W RGBW / FC LEDs delivering 23'000 lumens
    LED emitters controllable in 4 sections
    Compact form factor and fanless

    LIGHT SOURCE
    • Source:
      48x10
      W
      RGBW / FC LEDs
    • Luminous flux:
      (10°) 18'421 lm; (15°) 22'977 lm; (25°) 20'741 lm; (45°) 16'408
      lm
      @full
    • Lux:
      (10°) 37'370 lx; (15°) 30'888 lx; (25°) 12'884 lx; (45°) 2'739
      lx
      @3 m full
    • Lux:
      (10°) 13'453 lx; (15°) 11'120 lx; (25°) 4'638 lx; (45°) 986
      lx
      @5 m full
    • Source life expectancy:
      50.000 hrs (L70 @25° C / 77° F)
    OPTICS
    • Beam angle:
      15
      °
    • Field angle:
      27
      °
    • Additional optics:
      10° - 25° - 45° (optional)
    COLOUR SYSTEM
    • Colour mixing:
      RGBW / FC
    • CCT:
      CCT control through dedicated DMX channel
    • White presets:
      2.800 K ~ 10.000
      K
    • Colour wheel:
      virtual colour wheel with macros
    • Macros:
      several pre-build macros with adjustable speed
    DYNAMIC EFFECTS
    • FX generator:
      up to 4 linear
      controllable sections
    • Static colour mode:
      selection of static colour
    BODY
    • Tilt angle:
      0 ~ 130
      °
      with manual regulation
    • Body:
      sturdy die-cast aluminium body
    • Body colour:
      RAL 7012
    CONTROL
    • Protocols:
      DMX512, RDM
    • DMX channels:
      5 / 7 / 10 / 17 / 22
      channel
    • Pixel control:
      up to 4 linear
      controllable sections
    • RDM:
      RDM ready for remote monitoring and settings
    • Display:
      user interface through DATAMASTER external coder (not included)
    • Firmware upgrade:
      yes, via USB - DMX interface (UPBOX1) not included
    • Master/Slave:
      for synchronised operation of more units linked in a chain
    ELECTRONICS
    • Dimmer:
      linear 0 ~ 100% electronic dimmer
    • Dimmer curves:
      4
      selectable dimming modes available
    • Strobe / shutter:
      1 ~ 30
      Hz, electronic
    • Operating temperature:
      -20° C / +45° C (-4° F / +113° F)
    • LED Control:
      flicker free operation
    • Selectable PWM:
      600 ~ 25.000 Hz
    ELECTRICAL
    • Max power consumption:
      700
    • Mains power supply:
      100-240V - 50/60Hz
    • Max power consumption:
      521
      W
    • Max power consumption (at 120V):
      552
      W
    • Output (at 230V):
      4
      units on a single power line
    • Output (at 120V):
      2
      units on a single power line
    • Power factor:
      0,95
    PHYSICAL
    • Cooling:
      passive cooling and fan-free
    • Adaptors:
      XLR and Schuko 16A adaptors included
    • Signal connection:
      moulded IP signal IN/OUT connectors
    • Power connection:
      moulded IP power IN/OUT connectors
    • IP rating:
      66
      for outdoor installations
    • IK rating:
      08
    • Dimensions (WxHxD):
      584x304x93
      mm
    • Weight:
      14
      kg
    BOX CONTENT
    • 1 x ARCPOD48Q
    • 1 x SCHUKO - IP connection adapter
    • 1 x 5p XLR - IP connection male adapter
